Datasheet

Diabrotica virgifera virgifera (western corn rootworm)

Summary

  • Last modified
  • 11 October 2017
  • Datasheet Type(s)
  • Invasive Species
  • Pest
  • Vector of Plant Pest
  • Preferred Scientific Name
  • Diabrotica virgifera virgifera
  • Preferred Common Name
  • western corn rootworm
  • Taxonomic Tree
  • Domain: Eukaryota
  •   Kingdom: Metazoa
  •     Phylum: Arthropoda
  •       Subphylum: Uniramia
  •         Class: Insecta
  • Summary of Invasiveness
  • D. virgifera virgifera is thought to originate from Central America (Krysan and Smith, 1987). In the twentieth cen...

Don't need the entire report?

Generate a print friendly version containing only the sections you need.

Generate report

Pictures

Top of page
PictureTitleCaptionCopyright
Diabrotica virgifera virgifera (western corn rootworm); adult beetle. September, 2011. USA.
TitleAdult
CaptionDiabrotica virgifera virgifera (western corn rootworm); adult beetle. September, 2011. USA.
Copyright©Daren Mueller/Iowa State University/Bugwood.org - CC BY 3.0 US
Diabrotica virgifera virgifera (western corn rootworm); adult beetle. September, 2011. USA.
AdultDiabrotica virgifera virgifera (western corn rootworm); adult beetle. September, 2011. USA.©Daren Mueller/Iowa State University/Bugwood.org - CC BY 3.0 US
Diabrotica virgifera virgifera (western corn rootworm); adult, searching for pollen on corn silk. USA. Length ca.5mm.
TitleAdult
CaptionDiabrotica virgifera virgifera (western corn rootworm); adult, searching for pollen on corn silk. USA. Length ca.5mm.
Copyright©Tom Hlavaty/USDA Agricultural Research Service/Bugwood.org - CC BY 3.0 US
Diabrotica virgifera virgifera (western corn rootworm); adult, searching for pollen on corn silk. USA. Length ca.5mm.
AdultDiabrotica virgifera virgifera (western corn rootworm); adult, searching for pollen on corn silk. USA. Length ca.5mm.©Tom Hlavaty/USDA Agricultural Research Service/Bugwood.org - CC BY 3.0 US
Diabrotica virgifera virgifera (western corn rootworm); adult males.
TitleAdult males
CaptionDiabrotica virgifera virgifera (western corn rootworm); adult males.
Copyright©Stefan Töpfer/CABI
Diabrotica virgifera virgifera (western corn rootworm); adult males.
Adult malesDiabrotica virgifera virgifera (western corn rootworm); adult males.©Stefan Töpfer/CABI
Diabrotica virgifera virgifera (western corn rootworm); adults silk clipping on maize cobs.
TitleDamage symptoms
CaptionDiabrotica virgifera virgifera (western corn rootworm); adults silk clipping on maize cobs.
Copyright©Stefan Töpfer/CABI
Diabrotica virgifera virgifera (western corn rootworm); adults silk clipping on maize cobs.
Damage symptomsDiabrotica virgifera virgifera (western corn rootworm); adults silk clipping on maize cobs.©Stefan Töpfer/CABI
Diabrotica virgifera virgifera (western corn rootworm); larva. ca. 0.25", 6-7mm in length. USA.
TitleLarva
CaptionDiabrotica virgifera virgifera (western corn rootworm); larva. ca. 0.25", 6-7mm in length. USA.
Copyright©Scott Bauer/USDA Agricultural Research Service/Bugwood.org - CC BY 3.0 US
Diabrotica virgifera virgifera (western corn rootworm); larva. ca. 0.25", 6-7mm in length. USA.
LarvaDiabrotica virgifera virgifera (western corn rootworm); larva. ca. 0.25", 6-7mm in length. USA.©Scott Bauer/USDA Agricultural Research Service/Bugwood.org - CC BY 3.0 US
Diabrotica virgifera virgifera (western corn rootworm); larvae are slender, white to pale yellow, with a yellowish-brown head capsule and a brownish plate on the last abdominal segment.
TitleLarva
CaptionDiabrotica virgifera virgifera (western corn rootworm); larvae are slender, white to pale yellow, with a yellowish-brown head capsule and a brownish plate on the last abdominal segment.
Copyright©CIMMYT
Diabrotica virgifera virgifera (western corn rootworm); larvae are slender, white to pale yellow, with a yellowish-brown head capsule and a brownish plate on the last abdominal segment.
LarvaDiabrotica virgifera virgifera (western corn rootworm); larvae are slender, white to pale yellow, with a yellowish-brown head capsule and a brownish plate on the last abdominal segment.©CIMMYT
Eggs of Diabrotica virgifera virgifera.
TitleEggs
CaptionEggs of Diabrotica virgifera virgifera.
Copyright©Stefan Töpfer/CABI
Eggs of Diabrotica virgifera virgifera.
EggsEggs of Diabrotica virgifera virgifera.©Stefan Töpfer/CABI
Diabrotica virgifera virgifera (western corn rootworm); damage to root system.
TitleDamage symptoms
CaptionDiabrotica virgifera virgifera (western corn rootworm); damage to root system.
Copyright©CIMMYT
Diabrotica virgifera virgifera (western corn rootworm); damage to root system.
Damage symptomsDiabrotica virgifera virgifera (western corn rootworm); damage to root system.©CIMMYT
Diabrotica virgifera virgifera (western corn rootworm); life history. eggs; first instar; second instar; third instar; ready to pupate third instar; pupae in soil; young pupae; newly hatched adult.
TitleLife history
CaptionDiabrotica virgifera virgifera (western corn rootworm); life history. eggs; first instar; second instar; third instar; ready to pupate third instar; pupae in soil; young pupae; newly hatched adult.
Copyright©Stefan Töpfer/CABI
Diabrotica virgifera virgifera (western corn rootworm); life history. eggs; first instar; second instar; third instar; ready to pupate third instar; pupae in soil; young pupae; newly hatched adult.
Life historyDiabrotica virgifera virgifera (western corn rootworm); life history. eggs; first instar; second instar; third instar; ready to pupate third instar; pupae in soil; young pupae; newly hatched adult.©Stefan Töpfer/CABI

Identity

Top of page

Preferred Scientific Name

  • Diabrotica virgifera virgifera LeConte

Preferred Common Name

  • western corn rootworm

Other Scientific Names

  • Diabrotica filicornis Horn
  • Diabrotica virgifera LeConte
  • Diabrotica virgifera var. filicornis Gillette

International Common Names

  • English: Colorado corn rootworm; corn rootworm, Colorado; corn rootworm, western
  • Spanish: diabrotica del maiz; gusano de la raiz del maiz; gusano del raiz
  • French: chrysomèle des racines du maïs; chrysomèle des racines du maïs

Local Common Names

  • Germany: Westlicher Maiswurzelbohrer

EPPO code

  • DIABVI (Diabrotica virgifera)

Summary of Invasiveness

Top of page

D. virgifera virgifera is thought to originate from Central America (Krysan and Smith, 1987). In the twentieth century, Diabrotica virgifera virgifera became a major pest of maize in North America as maize growing areas increased (Krysan and Miller, 1986; Tallamy et al., 2005). The practice of continuous maize growing was largely responsible for the expanding range of D. virgifera virgifera.

D. virgifera virgifera was accidentally introduced at least three times from North America into Europe between the late 1980s and the early 2000s (Miller et al., 2005). There is no information about the pathways of introductions, or the process of its entry, or about its period of adaptation and establishment. Larvae-induced damage was recorded for the first time near Belgrade airport in former Yugoslavia in 1992 (Baca, 1994). The species became invasive and quickly spread throughout Central Europe in the 1990s and early 2000s. Although the larvae move relatively small distances, the adults fly to maize fields and are able to actively migrate several kilometres per year (Coats et al., 1986; Isard et al., 2000, Kiss et al., 2005b). In the laboratory, adults were observed to fly up to a maximum of 24 km on flight mills (Coats et al., 1986). Under field conditions, adults may additionally be carried by weather features such as cold fronts (Grant and Seevers, 1989) and thunderstorms (Onstad et al., 1999). Conclusively, the large-scale spread of D. virgifera virgifera varies a great deal between years and regions, sometimes reaching up to 60 to 80 km per year (Edwards et al., 1999; Baufeld and Enzian, 2005). Recently, several new isolated satellite introductions were reported around Paris (France), Basel (France and Switzerland), Amsterdam (The Netherlands), in Belgium and around London (UK) (Kiss et al., 2005b). All maize-growing areas of Europe, and in the long-term also of Asia, are at risk (Baufeld and Enzian, 2005) because this pest is likely to survive and develop wherever maize is grown. Its adaptability to different climatic conditions is also reflected by its broad distribution area from Northern Mexico, throughout the USA and up to Canada (Krysan and Miller, 1986).

Taxonomic Tree

Top of page
  • Domain: Eukaryota
  •     Kingdom: Metazoa
  •         Phylum: Arthropoda
  •             Subphylum: Uniramia
  •                 Class: Insecta
  •                     Order: Coleoptera
  •                         Family: Chrysomelidae
  •                             Genus: Diabrotica
  •                                 Species: Diabrotica virgifera virgifera

Notes on Taxonomy and Nomenclature

Top of page

First described as Diabrotica virgifera by LeConte (1868), the taxonomic history of this species has seen three changes: Diabrotica filicornis (Horn, 1893), Diabrotica virgifera var. filicornis (Gillette, 1910) and Diabrotica virgifera virgifera (Krysan et al., 1980). For a complete description of D. virgifera virgifera, refer to Krysan and Smith (1987).

Description

Top of page Eggs

Embryonic stage at diapause consists of a flattened oval egg, ca 500 µm long, consisting of undifferentiated cells representing the embryonic primordium and the amnion.

Larvae

Three larval instars. Larvae are slender, white to pale yellow, with a yellowish-brown head capsule and a brownish plate on the last abdominal segment. The third instar is about 10 mm long (Chiang, 1973).

Pupae

Pupae are naked and white, turning brownish before adult emergence, and are found in earthen cells in the soil near plant roots.

Adults

Adults are elongate, ca 5 mm (range 4.4-6.8 mm), greenish-yellow, with parallel yellow humeral plicae, with distinct piceous elytral vittae; lateral margin widest medially. The pronotum is shiny and yellow. The elytra are straw yellow, each with one humeral and one sutural vitta ending near the apex; humeral plicae are distinct. There are three discal sulci. The scutellum is buff. The head is shiny; the vertex is amber; the labrum and clypeus are piceous. Antennae of males are about 4.2 mm and longer than those of females. Segment three is 1.5 times longer than segment two. Segments two and three combined equal the length of segment four. The sterna are straw yellow, the episternites tawny and piceous on sutures. Legs are yellow to tawny, with the outer edge of femora piceous. The abdomen is yellow. The widths of the piceous humeral and sutural elytral vittae are highly variable (Krysan et al., 1980; Krysan and Smith, 1987).

Distribution

Top of page

D. virgifera virgifera, which originates from the USA, was recorded for the first time in the former Yugoslavia in 1992 and has quickly spread to become a threat to maize in Europe (Gerginov and Tomov, 1995). The practice of growing maize continuously is largely responsible for the expanding range of D. virgifera virgifera in North America.

See also Edwards (2006), CABI/EPPO (1998, No. 63) and http://www.eppo.org/QUARANTINE/Diabrotica_virgifera/diabrotica_virgifera.htm [EPPO, 2006 #9321].


Distribution Table

Top of page

The distribution in this summary table is based on all the information available. When several references are cited, they may give conflicting information on the status. Further details may be available for individual references in the Distribution Table Details section which can be selected by going to Generate Report.

Continent/Country/RegionDistributionLast ReportedOriginFirst ReportedInvasiveReferenceNotes

North America

CanadaRestricted distributionIntroduced Invasive Krysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-OntarioPresentIntroducedKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-QuebecRestricted distributionCABI/EPPO, 2012; EPPO, 2014
MexicoPresentNative Not invasive Krysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
USAWidespreadIntroduced Invasive Edwards, 2006; CABI/EPPO, 2012; EPPO, 2014
-AlabamaPresentCABI/EPPO, 2012; EPPO, 2014
-ArizonaPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-ColoradoWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-ConnecticutPresentCABI/EPPO, 2012; EPPO, 2014
-DelawarePresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-GeorgiaPresentCABI/EPPO, 2012
-IdahoPresentCABI/EPPO, 2012; EPPO, 2014
-IllinoisWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-IndianaWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-IowaWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-KansasWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-KentuckyPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-LouisianaPresentCABI/EPPO, 2012; EPPO, 2014
-MainePresentCABI/EPPO, 2012; EPPO, 2014
-MarylandPresentCABI/EPPO, 2012; EPPO, 2014
-MassachusettsPresentCABI/EPPO, 2012; EPPO, 2014
-MichiganPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-MinnesotaWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-MissouriWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-MontanaPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-NebraskaWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-New HampshirePresentCABI/EPPO, 2012; EPPO, 2014
-New JerseyPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-New MexicoPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-New YorkPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-North CarolinaPresentCABI/EPPO, 2012
-North DakotaPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-OhioPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-OklahomaPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-PennsylvaniaPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-Rhode IslandPresentCABI/EPPO, 2012; EPPO, 2014
-South DakotaWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-TexasPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-UtahPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-VirginiaPresentCABI/EPPO, 2012; EPPO, 2014
-WashingtonPresentCABI/EPPO, 2012
-West VirginiaPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-WisconsinWidespreadKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014
-WyomingPresentKrysan and Smith, 1987; CABI/EPPO, 2012; EPPO, 2014

Central America and Caribbean

Costa RicaPresentNative Not invasive CABI/EPPO, 2012; EPPO, 2014
GuatemalaPresentNative Not invasive CABI/EPPO, 2012; EPPO, 2014
NicaraguaPresentNative Not invasive CABI/EPPO, 2012; EPPO, 2014

Europe

AlbaniaRestricted distributionCABI/EPPO, 2012; EPPO, 2014
AustriaRestricted distributionIntroduced2002 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
BelarusPresent, few occurrencesCABI/EPPO, 2012; EPPO, 2014
BelgiumTransient: actionable, under eradicationIntroduced2003 Invasive Kiss et al., 2005b; IPPC, 2010; CABI/EPPO, 2012; EPPO, 2014
Bosnia-HercegovinaWidespreadIntroduced1997 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
BulgariaWidespreadIntroduced1998 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
CroatiaWidespreadIntroduced1995 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
Czech RepublicPresent, few occurrencesIntroduced2002 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
DenmarkAbsent, confirmed by surveyEPPO, 2014
EstoniaAbsent, confirmed by surveyEPPO, 2014
FinlandAbsent, no pest recordEPPO, 2014
FranceRestricted distributionIntroduced2002 and 2003 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2012; EPPO, 2014
-France (mainland)Present, few occurrencesCABI/EPPO, 2012
GermanyTransient: actionable, under eradicationCABI/EPPO, 2012; Dicke et al., 2014; EPPO, 2014
GreeceRestricted distributionMichaelakis et al., 2010; CABI/EPPO, 2012; EPPO, 2014
-Greece (mainland)Restricted distributionCABI/EPPO, 2012
HungaryWidespreadIntroduced1995 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
ItalyRestricted distributionIntroduced1998, 2000 and 2002 Invasive Kiss et al., 2005b; EPPO, 2011; CABI/EPPO, 2012; EPPO, 2014
-Italy (mainland)PresentCABI/EPPO, 2012
MontenegroPresentCABI/EPPO, 2012; EPPO, 2014
NetherlandsEradicatedIntroduced2003 and 2005 Invasive Kiss et al., 2005b; NPPO of the Netherlands, 2013; IPPC, 2006; CABI/EPPO, 2012; EPPO, 2014
PolandRestricted distributionIntroduced2005 Invasive Edwards, 2006; CABI/EPPO, 2012; EPPO, 2014
RomaniaWidespreadIntroduced1996 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
Russian FederationPresent, few occurrencesCABI/EPPO, 2012; EPPO, 2012; EPPO, 2014
-Southern RussiaPresent, few occurrencesCABI/EPPO, 2012; EPPO, 2014
SerbiaRestricted distributionCABI/EPPO, 2012; EPPO, 2014
SlovakiaWidespreadIntroduced2000 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
SloveniaPresent, few occurrencesIntroduced2003Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
SpainAbsent, confirmed by surveyEPPO, 2014
SwitzerlandTransient: actionable, under eradicationIntroduced2000 and 2003 Invasive Kiss et al., 2005b; EPPO, 2011; CABI/EPPO, 2012; EPPO, 2014
UKPresent, few occurrencesIntroduced2003 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; IPPC, 2013; EPPO, 2014; IPPC, 2014
-England and WalesPresent, few occurrencesIntroduced2003Kiss, 2005b; CABI/EPPO, 2012; IPPC, 2013; EPPO, 2014
UkrainePresent, few occurrencesIntroduced2001 Invasive Kiss et al., 2005b; CABI/EPPO, 2012; EPPO, 2014
Yugoslavia (Serbia and Montenegro)WidespreadIntroduced1992 Invasive Baca, 1994; Sivcev et al., 1994

History of Introduction and Spread

Top of page

D. virgifera virgifera is thought to originate from Central America (Krysan and Smith, 1987).

In the twentieth century, D. virgifera virgifera became a major pest of maize in North America as maize-growing areas increased (Krysan and Miller, 1986; Tallamy et al., 2005). The practice of continuous maize growing is largely responsible for the expanding range of D. virgifera virgifera. D. virgifera virgifera was accidentally introduced several times into Europe from North America between the late 1980s and the early 2000s (Miller et al., 2005). Larvae-induced damage was recorded for the first time near Belgrade airport in former Yugoslavia in 1992 (Baca, 1994). The species became invasive and quickly spread throughout Central Europe, becoming a threat to maize production all over Europe (Gerginov and Tomov, 1995; Kiss et al., 2005b).

See also Kiss et al. (2005b), Miller et al. (2005) and CABI/EPPO (1998, No. 63).

Risk of Introduction

Top of page

D. virgifera virgifera is on the quarantine list of EPPO and of the European Union member countries (Commission decision 2003/766/EC) (Toepfer and Kuhlmann, 2004b). It spread throughout Central Europe in the 1990s and early 2000s. Multiple introductions also occurred in Western Europe. All maize-growing areas of Europe, and in the long-term also of Asia, are at risk (Baufeld and Enzian, 2005) because it is likely to survive and develop wherever maize is grown. The fact that D. virgifera virgifera spreads relatively slowly by natural means, except when carried by storms, offers some potential for its containment (Furlan et al., 2002). However, the rate of spread still poses a serious threat to the whole of Europe.

Hosts/Species Affected

Top of page

D. virgifera virgifera has a larval host range restricted to certain Poaceae. The original host range of its larvae in Central America is uncertain (Moeser and Hibbard, 2005).

For lists of secondary hosts, see Branson and Ortman (1967, 1970, 1971), Breitenbach et al. (2005), Moeser and Hibbard (2005).

Host Plants and Other Plants Affected

Top of page
Plant nameFamilyContext
Cucurbita (pumpkin)CucurbitaceaeOther
Cucurbita pepo (marrow)CucurbitaceaeOther
Cucurbitaceae (cucurbits)CucurbitaceaeOther
Fabaceae (leguminous plants)FabaceaeOther
Glycine max (soyabean)FabaceaeOther
Helianthus annuus (sunflower)AsteraceaeOther
Hordeum (barleys)PoaceaeOther
Panicum (millets)PoaceaeOther
Poaceae (grasses)PoaceaeMain
Polyphagous (polyphagous)Other
Setaria (Foxtailmillet)PoaceaeOther
Tripsacum dactyloides (eastern gamagrass (USA))PoaceaeOther
Triticum (wheat)PoaceaeOther
Zea mays (maize)PoaceaeMain

Growth Stages

Top of page Flowering stage, Vegetative growing stage

Symptoms

Top of page Newly-hatched larvae feed primarily on root hairs. As the larvae grow and their food requirements increase, they burrow into roots. Larval damage is usually most severe after the secondary root system is well established and brace roots are developing. Root tips appear brown and often contain tunnels. In many cases, they are chewed back to the base of the plant. Larvae may be found tunnelling in larger roots and occasionally in the plant crown. Larvae may burrow through plants near the base, causing stunting or death of the growing point and frequently causing tillering. Root feeding commences shortly after plant emergence and early symptoms are expressed as drought or nutrient deficiencies. Plant lodging occurs later in plant development. Sites of larval damage are often pathways for infection by disease pathogens, resulting in root rots.

Adult beetles cause damage by feeding principally on pollen, silk and young kernels. Silk clipping near the husk during anthesis can cause reduced seed set in maize, which may only be observed at the time of harvest.

List of Symptoms/Signs

Top of page

Fruit

  • external feeding

Growing point

  • dwarfing; stunting
  • wilt

Inflorescence

  • external feeding

Leaves

  • external feeding

Roots

  • external feeding
  • internal feeding

Biology and Ecology

Top of page

The bionomics of D. virgifera virgifera have been reviewed by Chiang (1973). D. virgifera virgifera is univoltine. Adults emerge in the summer and are prevalent in maize fields until the autumn. Eggs are the overwintering stage and are generally concentrated in the top 5-20 cm of soil, although they are situated deeper in dry soils. Eggs require a cold-induced diapause period before hatching, although a small proportion of the population may hatch during a warm, prolonged autumn. The developmental rates of post-diapause eggs of D. virgifera virgifera were investigated and the lower development threshold (10.5°C) was determined by linear regression; completion of post-diapause egg development required 258 day-degrees C above this temperature (Schaafsma et al., 1991). For the emergence of 50% of first-instar larvae, about 265 degree days are needed above a temperature of 11°C in Ontario, Canada (Schaafsma et al., 1993), whereas 292 degree-days above 11°C are needed in South Dakota, USA (Fisher, 1989), and 354 degree-days above 11.2°C in Illinois, USA (Levine et al., 1992 b). Maize has a developmental threshold of 10°C and is planted as early as the soil is free of frost (Aldrich, 1978). In Central Europe, larval emergence usually starts at the beginning of May.

Three larval instars develop in and on the roots. As the temperature increases, development time decreases, up to 33°C when no larvae survive the second instar. As the temperature increases, the proportion of time spent in the third instar increases and the proportion for the first instar decreases (Jackson and Elliot, 1988). The proportions of development time spent in different instars were similar for males and females over a range of temperatures (15-31.5°C) (Jackson and Elliot, 1988).

For the emergence of adults, about 415 degree-days above 9°C are needed in South Dakota, USA (Jackson and Elliot, 1988). In regions with warm, dry summers, numbers of D. virgifera virgifera beetles decline rapidly in mid-August. In climates experiencing cooler summers, adult beetles may be found as long as green maize plants are available. For adults of D. virgifera virgifera maintained at five temperatures (16, 19.5, 23, 26.5 and 30°C), the mean number of eggs laid per female was greatest (602) at 26.5°C and least (295) at 16.0°C. The median lifespan decreased with increasing temperature from 13.8 weeks at 19.5°C to 7.9 weeks at 30.0°C (Elliott et al., 1990a). A reduction in the quality of food associated with maize plant maturity significantly reduced the oviposition period, fecundity and lifespan of D. virgifera virgifera (Elliott et al., 1990b). Greater longevity and increased fecundity has also been observed in early-emerging females of D. virgifera virgifera; beetles emerging during the first part of the growing season appeared to be fitter than their late-emerging counterparts (Boetel and Fuller, 1997). However, Naranjo and Sawyer (1987) report that adults emerging relatively early and late in the field differed in size but did not significantly differ in reproductive potential. The natural mortalities of D. virgifera virgifera life stages were reviewed by Toepfer and Kuhlmann (2005).

Genetics

Populations of D. virgifera virgifera usually show high levels of genetic diversity; and a mean allelic diversity ranging from 7.3 to 8.6, and expected heterozygosity ranging from 0.600 to 0.670 was reported (Kim and Sappington, 2005). D. virgifera virgifera populations exhibit little genetic differentiation as a whole across the geographic range of nine US states (western Texas and Kansas to New York and Delaware). There was no evidence for a genetic bottleneck in any D. virgifera virgifera population sampled in North America (Kim and Sappington, 2005); however, several bottlenecks were reported for the introduction areas in Europe (Miller et al., 2005).

Natural enemies

Top of page
Natural enemyTypeLife stagesSpecificityReferencesBiological control inBiological control on
Beauveria bassiana Pathogen
Carabidae Predator Larvae
Harpalus pensylvanicus Predator
Hypoaspis aculeifer Parasite
Lasius neoniger Predator
Myrmica americana Predator
Pheidole bicarinata Predator
rickettsia-like organisms Pathogen

Notes on Natural Enemies

Top of page

Natural enemies of Diabrotica spp. are listed by Kuhlmann and van der Burgt (1998) in relation to their possibilities for biological control in Europe.

Means of Movement and Dispersal

Top of page

Natural dispersal

Although the larvae move relatively small distances, the adults fly to maize fields and are able to migrate over short and longer distances. In addition, adults may be carried by weather features such as cold fronts (Grant and Seevers, 1989) and thunderstorms (Onstad et al., 1999).

Vector transmission

D. virgifera virgifera can transmit Maize chlorotic mottle virus (Jensen, 1985).

Agricultural practices

Maize fields with early flowering maize hybrids may become donor fields when flowering in these fields finishes. Conversely, later flowering maize fields are attractive to beetles and thus may become trap crops.

Movement in trade

There are no obvious means of intercontinental dispersal by trade, as it is unlikely that the insects would be carried by consignments of seeds or grain. However, its multiple introductions into Europe between the late 1980s and early 2000s (Miller et al., 2005) suggest a new but unknown pathway via aeroplanes that carried D. virgifera virgifera but not other Diabrotica pest species. It is possible that D. virgifera virgifera is spread within Europe by consignments of green maize.

Plant Trade

Top of page
Plant parts liable to carry the pest in trade/transportPest stagesBorne internallyBorne externallyVisibility of pest or symptoms
Bulbs/Tubers/Corms/Rhizomes larvae Yes Yes Pest or symptoms not visible to the naked eye but usually visible under light microscope
Flowers/Inflorescences/Cones/Calyx adults Yes Pest or symptoms usually visible to the naked eye
Fruits (inc. pods) adults Yes Yes Pest or symptoms usually visible to the naked eye
Growing medium accompanying plants eggs Yes Pest or symptoms usually invisible
Leaves adults Yes Pest or symptoms usually visible to the naked eye
Roots larvae Yes Yes Pest or symptoms not visible to the naked eye but usually visible under light microscope
Stems (above ground)/Shoots/Trunks/Branches adults Yes Pest or symptoms usually visible to the naked eye
Plant parts not known to carry the pest in trade/transport
Bark
Seedlings/Micropropagated plants
True seeds (inc. grain)
Wood

Impact Summary

Top of page
CategoryImpact
Animal/plant collections None
Animal/plant products None
Biodiversity (generally) None
Crop production Negative
Environment (generally) Negative
Fisheries / aquaculture None
Forestry production None
Human health None
Livestock production None
Native fauna Negative
Native flora None
Rare/protected species None
Tourism None
Trade/international relations Negative
Transport/travel Negative

Impact

Top of page

D. virgifera virgifera together with D. barberi are the most serious insect pests of maize in the major maize-producing states of the north-central USA (Levine and Oloumi-Sadeghi, 1991). The larvae damage maize roots, which reduces the ability of the plant to absorb water and nutrients from the soil and causes harvesting difficulties due to plant lodging. Adult feeding on silks interferes with pollination. The quantification of yield loss varies according to cultivation practices and location of the field. Generally yield losses have been estimated at around 15% for every node (i.e. circle of roots) damaged from larval feeding (Tinsley et al., 2013).

The costs of soil insecticides to control larval damage to roots, and of aerial spray to reduce adult damage to silks, when combined with crop losses approached US$1000 million annually in the 1980s (Metcalf, 1986; Krysan and Miller, 1986). Since the introduction of the beetle into Europe at the beginning of the 1990s, economic losses have been recorded from Serbia, Hungary, Croatia, Romania, Italy and Austria. The damage potential in Europe is estimated at 472 million Euros annually, when no control measures are implemented (Wesseler and Fall, 2010).

Environmental Impact

Top of page

In the USA, granular insecticides and insecticide-treated maize seeds were applied on a maize-growing area of over 5 million hectares in 2000 (Ward et al., 2005). Transgenic maize varieties were adopted quickly after their release in the USA (e.g., Cry3Bb1 Bt maize increased from 0.2 million ha in 2003 to 12.8 million ha in 2009) (Devos et al., 2013). This initially led to a reduction in insecticide use from 25% of maize treated in 2005 to 9% in 2010. Since the emergence of resistance issues with transgenic maize in 2011, the use of soil insecticides increased again as farmers apply it as an insurance against a possible D. virgifera virgifera problem in Bt maize.

The use of neonicotinoids (a.i. clothianidin) as a preventive measure for D. virgifera virgifera eradication in Germany led to a high number of bee poisonings in 2008 (more than 11,500 honey bee colonies were affected). The abrasion of dust from maize seeds during sowing resulted in a contamination of pollen and nectar in nearby surroundings. Additionally a higher rate of clothianidin was used for the eradication programme than for other pest control measures (e.g. wireworms) (Pistorius et al., 2009). This scenario initiated a temporary ban on neonicotinoids in most EU countries.

Impact: Biodiversity

Top of page

D. virgifera virgifera has a low impact on biodiversity because its host plant, maize, is exotic in large areas of North America and Europe and maize fields are therefore relatively poor in arthropod diversity.

Social Impact

Top of page

The social impact of D. virgifera virgifera has not been quantified.

Detection and Inspection

Top of page

To detect low population levels of adult D. virgifera virgifera in July and August or to detect early infestations in June or early July, pheromone baited traps are most effective and are commercially available in North America and Europe (Hesler and Sutter, 1993). The sex pheromone racemic 8-methyl-2-decane2-ol-propanoate serves as bait on, for example, a transparent sticky trap to capture males with high sensitivity (Tóth, 2003). These traps are of simple design and are an inexpensive means of D. virgifera virgifera detection. One trap per field <5 ha) must be placed at the ear level of the maize plant and changed every 3 to 4 weeks. With the same trap type, the increase in emerging adult populations can be monitored until their number exceeds 100 per trap per week. Field infestations of D. virgifera virgifera can also be detected by surveying flowering maize plants for adults. 'Goose-necking' of the maize stalk prior to flowering indicates heavy root damage, which is often caused by rootworm larval feeding (Krysan and Miller, 1986).

The Diabrotica ID can be used to identify species of Diabrotica.

Similarities to Other Species/Conditions

Top of page

D. virgifera virgifera is closely related to the subspecies D. virgifera zea; for details refer to Krysan et al. (1980) and Krysan and Smith (1987). D. virgifera virgifera has yellowish elytra with black vittae, whereas D. virgifera zeae is largely green and has entirely pale elytra or with a narrow piceous vitta. D. virgifera virgifera is readily distinguished from D. barberi by the presence of piceous markings on the femora or amber coloration on their dorsal edge. The femora of D. longicornis are pale and uniform in colour (Krysan and Smith, 1987). Other North American species have more distinct spots or bands on the elytra. D. virgifera virgifera and D. barberi occur in the same area for a large part of their range. Their biology and behaviour is very similar (Levine and Chan, 1990). At least under laboratory conditions, they are also interfertile.

Injury caused by D. virgifera virgifera can be confused with that caused by Diatraea spp., sugarcane beetles (Euetheola humilis rugiceps) or wireworms (Elateridae).

Prevention and Control

Top of page

Introduction

See Levine and Oloumi-Sadeghi (1991), Toepfer et al. (2005b), Gray et al. (2009), Ivezic et al. (2009), Narva et al. (2013) and Van Rozen and Ester (2010) for a review of management strategies for D. virgifera virgifera. Further information can also be found in a series of reviews in a special issue of Agricultural and Forest Entomology on D. virgifera virgifera research (Agricultural and Forest Entomology (2009), 11(1):3-60).

Phytosanitary Measures

The capacity for natural spread of D. virgifera virgifera is such that it is difficult to propose measures for its prevention. European countries have put in place a monitoring network using pheromone traps to follow spread. In cases of new introductions, immediate insecticide treatments have to be carried out, no maize is allowed to be grown in a focus zone around the introduction point and crop rotation is obligatory in a safety zone around the focus zone (Byrne, 2003).

The main aim at present is to contain D. virgifera virgifera in Europe and to delay its impact as much as possible, mainly by applying crop rotation.

See European Commission decision 2003/766/EC (Byrne, 2003).

In 2014 the European Commission decided to withdraw the recognition of D. virgifera virgifera as a regulated harmful organism with quarantine status by deleting it from Annex 1 to Council Directive 2000/29/EC. The containment measures were also not regarded as successful and Decision 2003/766/EC was therefore repealed. EU Member states are now responsible for providing guidelines for D. virgifera virgifera management, especially taking the principles of IPM into account (Borg, 2014).

Cultural Control

Crop rotation is an effective control method for D. virgifera virgifera as the eggs are mainly laid in maize, and the larvae must feed on maize roots to complete their development (Ostlie and Noetzel, 1987; Levine and Oloumi-Sadeghi, 1991). However, a 100% crop rotation would be too strict as an 80% rotation of maize can keep D. virgifera virgifera below the economic threshold. In some cases (e.g. Serbia) even a 60% rotation was sufficient for control. The economic threshold is usually reached when less than 40% of maize fields are rotated. Rotation of each field within 3 years can also lead to about 20% fewer fields that need to be rotated (Szalai et al., 2013).

In principle, all possible crops, fallows or vegetables can be rotated with maize for D. virgifera virgifera management (Kiss et al., 2005a). However, certain crops, such as soyabean or monocotyledonous crops, might be less promising in long-term rotation with Diabrotica-infested maize fields. Many Poaceae are known to serve to some degree as secondary food plants for D. virgifera virgifera larvae (Branson and Ortman, 1967, 1970; Moeser, 2003; Moeser and Hibbard, 2005) and adults feed on nearly every pollen source (Moeser and Hibbard, 2005). However, larval damage on cultivated poaceous plants other than maize has not yet been recorded. In the corn belt of the USA, where soyabean was rotated with maize regularly and over many years, an increased oviposition of D. virgifera virgifera into soyabean was observed and larvae developed in the maize planted in the following year ('crop rotation resistance phenotype') (Gray et al., 1998, 2009). This rotation resistance developed from a decreased fidelity to maize by D. virgifera virgifera females as a consequence of a limited defined crop rotation scheme (Levine et al., 2002). Damage to rotated maize was first reported in an east-central region of Illinois and continued to spread throughout the corn belt (Gray et al., 2009) but at a slow expansion rate (Dunbar and Gassmann, 2013). Furthermore, crop rotation may not be completely effective in 1-year rotations due to the presence of volunteer maize. D. virgifera virgifera has low survivorship <0.1%) over two winters of diapause, but a 1-year rotation may select for rootworms with extended diapause (Krysan et al., 1984).

Most studies have found no significant differences in D. virgifera virgifera oviposition among various tillage practices. However, no-till appears to have the lowest egg mortality.

Delayed planting may result in decreased root damage as eclosed larvae can only survive a few days without feeding on suitable hosts. If planting is delayed until early June, root damage is negligible and soil insecticide usage is not warranted (Musick et al., 1980). Later flowering maize can attract D. virgifera virgifera from surrounding infested maize fields. Thus, late-planted strips of maize can be used as trap crops, although this technique is not widely practised, as its effectiveness is inconsistent.

Biological Control

D. virgifera virgifera has few effective natural enemies in its area of origin in Central America (Eben and Barbercheck, 1996; Kuhlmann and van der Burgt, 1998). In North America, natural enemies undoubtedly help to reduce and stabilize rootworm populations but other control interventions are normally required to bring D. virgifera virgifera populations below an economic threshold. In Europe, host-specific and/or effective indigenous natural enemies do not attack any of the life stages of D. virgifera virgifera (Toepfer and Kuhlmann, 2004a).

Classical biological control

Classical biological control provides an opportunity to reconstruct the natural enemy complex of D. virgifera virgifera populations in Europe (Kuhlmann and Burgt, 1998) and partly in North America. The natural enemy complex of Diabrotica species was surveyed in their area of origin in Central America (Kuhlmann et al., 2005) and Celatoria compressa was the only parasitoid found on the target species, D. virgifera virgifera. Its host range is considered to be restricted to Diabroticite beetles, and thus C. compressa would be safe for introduction because direct and indirect impacts on other organisms would be extremely low (Kuhlmann et al., 2005).

Inundative biological control

Entomopathogenic nematodes have great potential as biological control agents of D. virgifera virgifera (Cabanillas et al., 2005). Several commercially available nematode species have proven effective at killing D. virgifera virgifera larvae; for details, see Cabanillas et al. (2005) and Toepfer et al. (2005a). The nematode species Heterorhabditis bacteriophora has been evaluated as a control agent across numerous studies on a field scale and could reach similar control efficacies to commercially available insecticide treatments (Toepfer, 2010a, b). The first large scale applications of nematodes as a commercial product for D. virgifera virgifera control was carried out in Austria in 2014 (product name: DIANEM ®).

The entomopathogenic fungi Beauveriabassiana and Metarhiziumanisopliae naturally attack D. virgifera virgifera (Toepfer and Kuhlmann, 2004a; Pilz, 2008; Rudeen et al., 2013). Diabrotica populations in the USA are not usually regulated by fungi (Maddox and Kinney, 1989). However, fungi-based products are registered against soil pests in several countries (Inglis et al., 2001) suggesting further research should be carried out towards the development of a fungal biocontrol product against D. virgifera virgifera (Toepfer et al., 2005b). The commercially available M. anisopliae strain BIPESCO5/F52 (product name: GranMet) is included in Annex 1 of Directive 91/414/EEC. Its efficacy against D. virgifera virgifera in the field is currently lower than with insecticides and nematodes (Pilz et al., 2009) but opens further options for biological control. The EU project 'InBioSoil' (www.inbiosoil.uni-goettingen.de) further explores the potential of BIPESCO5 through the use of fungal formulations for soil application and efficacy enhancing agents (e.g. semiochemicals).

Host-Plant Resistance

Native resistance

Conventional breeding for resistance has resulted in germplasm with moderate levels of resistance to Diabrotica feeding (Knutson et al., 1999). There is currently no maize cultivar with native resistance available against D. virgifera virgifera, due to the limited success of conventional breeding strategies in the past (Moeser and Hibbard, 2005). The predominant mechanism for resistance is tolerance rather than antibiosis or antixenosis, for example, some maize cultivars demonstrate a tolerance to drought stress and larval feeding through the ability to regenerate roots (Branson et al., 1982). Hydroxamic acids have been identified as resistance factors to D. virgifera virgifera larvae in maize root tissue (Xie et al., 1990) and may occur in some commercial hybrids (Assabgui et al., 1993). Large screenings with a focus on root injury evaluation after artificial egg infestation identified resistance genotype but with no information on the underlying resistance mechanism. The use of more advanced genetic/genomic screening techniques (QTL, micorarrays and metabolite analysis) offers the potential to develop non transgenic maize hybrids with antibiosis against D. virgifera virgifera (Gray et al., 2009). The first steps in this process have been made (e.g. 'SUM' cultivars; El-Khishen et al., 2009) and research is ongoing, especially in Europe, to develop breeding programmes for native resistance (Ivezic et al., 2009).

Genetically modified resistance

Genetically modified maize varieties with Bt toxin expressed in their roots (Cry3Bb1, Cry34Ab1/ Cry35Ab1 and mCry3A) can avoid larval damage and have been commercialised in the USA since 2003 (Ward et al., 2005). Seven transgenic events targeting rootworms were released between 2003 and 2013 including pyramided traits with more than one Bt protein and different modes of action (first on the market SmartStax ® in 2009). More stacked Bt events were released in 2014 (eCry3.1Ab+mCry3A). The transgenic maize cultivars have been proven as highly effective (>95%) and were quickly adapted by farmers. Insect resistance management (IRM) plans were established to delay resistance to Bt maize by planting a refuge with a non Bt crop habitat.

In 2009, four populations of D. virgifera virgifera with evolved resistance to Cry3Bb1 were identified in Iowa (Gassmann et al., 2011, 2012; Devos et al., 2013). Resistance was probably triggered through the extensive use of the same Bt-maize repeatedly and exclusively (Devos et al., 2013). The ability of cross resistance to other single events (e.g., Cry34Ab1/ Cry35Ab1) is also possible (Devos et al., 2013). Caution should therefore be taken to mitigate any risks of resistance to other Bt events. Resistance models predict that resistance may be delayed with pyramided traits in Bt-maize in the absence of potential cross resistance (Onstad and Meinke, 2010). The use of these pyramided traits is increasing (Storer et al., 2012) but the Bt maize 'landscape' currently comprises a mixture of single and multiple toxins.

Growing of Bt maize in Europe is often denied by EU or national authorities (some countries have banned the use of Bt maize under the safeguard clause Articles 16 and 18) so there is currently no transformed Bt event for D. virgifera virgifera resistance authorised for cultivation (Meissle et al., 2011).

The use of RNAi (RNA interference), in which double-stranded RNA (dsRNA) molecules trigger gene silencing in a sequence specific manner, could provide a new option for  D. virgifera virgifera control (Miyata et al., 2014). D. virgifera virgifera larvae are sensitive to an oral RNAi approach and transgenic plants expressing D. virgifera virgifera  dsRNAs show a significant reduction in larval feeding damage (Baum et al., 2007). Further studies will evaluate its potential as a management option and the likelihood for commercial use (Burand and Hunter, 2013).

Chemical Control

Chemical control mainly focuses on the larval stage of D. virgifera virgifera as it is economically more feasible (Gerber et al., 2005). Preventive applications of granular soil insecticides or seed treatments against D. virgifera virgifera larvae are widely used as a management strategy in fields where maize is cultivated continuously. However, this strategy protects the roots within the treated band in the maize row but does not reduce populations of larvae that complete their development outside the treated band on peripheral roots (Gray et al., 1992; Boetel et al., 2003; Furlan et al., 2006). Therefore little (if any) resistance against soil insecticides has been documented so far.

Physiochemical properties, degradability, formulation and inherent toxicity are important factors influencing the efficacy of soil-applied insecticides. Tillage practices do not seem to affect the distribution of insecticides in the soil profile although reduced tillage significantly reduces surface runoff (Felsot et al., 1990). Application rates, placement and incorporation are also among the mechanical factors that influence rootworm larvae.

The history of soil-applied insecticides in the USA used to treat D. virgifera virgifera larvae includes the use of chlorinated hydrocarbons (in the 1940s and 1950s) and carbamates or organophospates (since the 1960s). Chemical control of larvae also involves seed treatments with neonicotinoids (e.g. clothianidin). Soil treatments with granular or liquid formulations are dominated by organophospates and synthetic pyrethroids or a combination of the two insecticide classes (Gassmann and Weber, 2013). The WHO has classified some of these insecticides as hazardous pesticides whose use should be restricted (http://www.who.int/ipcs/publications/pesticides_hazard_2009.pdf).

In Europe the main soil insecticides in use are neonicotinoids (clothianidin as seed treatment). Since the temporary ban of clothianidin (see Environmental Impact), the use of pyrethroids is the only option for chemical control of D. virgifera virgifera larvae. Their use in some EU countries is, however, also limited as they can be applied on an approved area (e.g. cypermethrin on 9% of cultivated maize in Austria in 2014) or over a specific time span. This subsequently leaves chemical control as a limited control option for larvae.

Control of adult populations is usually confined to seed production fields and is only occasionally applied to commercial fields. Foliar sprays are generally costly and are affected by rainfall and sprinkler irrigation; they require precise timing to target ovipositing females and must remain active against immigrating gravid females and extended beetle emergence. The most common insecticides to spray against adults in the USA are carbamates (e.g. carbaryl), organophosphates (chlorpyrifos) and synthetic pyrethroids (e.g. bifenthrin). Several cases of resistance to insecticides are known for D. virgifera virgifera, such as regionally developed resistance to organophosphates, carbamates, e.g. carbaryl or chlorinated hydrocarbons (Meinke et al., 1998; Scharf et al., 2000). Moreover, their honeybee toxicity, re-entry interval, and application difficulties due to maize height are limiting factors for application. These insecticides also endanger the biological control of the European corn borer, Ostrinia nubilalis, with Trichogramma parasitoids. The 'attract and kill' method effectively reduces the number of D. virgifera virgifera adults (Chandler, 1998). Therein, a small amount of insecticide (usually 10% of the registered amount, e.g. carbaryl) is combined with natural feeding stimulants/arrestants or attractants, e.g. cucurbitacins (Invite ®)(Borianai et al., 2006).This approach is used on a limited basis and performs best in states like Kansas with a semi-arid climate and low adult populations (Borianai et al., 2006). In Europe the same insecticidal compounds are used (except for carbamate) but are mainly confined to Eastern European countries (Van Rozen and Ester, 2010). Beetles can also be sprayed with a neonicotinoid (a.i. thiacloprid) in EU countries.

Due to the plant size at the time of adult spraying, high clearance tractors are needed for insecticide application. Most farmers in Europe cannot access such equipment, making adult management more difficult.

Aerially applied treatments against adults are not normally used unless there is an average of five beetles per ear and the maize is less than 50% silk and not yet pollinated. Control should be instigated only if an economic level of rootworm beetles is observed. Once the silks turn brown, control is no longer necessary. The most commonly used insecticides include carbaryl, fenvalerate and esfenvalerate, malathion and permethrin. Other insecticides registered for rootworm beetle control in the USA include chlorpyrifos and diazinon; these compounds are more toxic to humans. The use of aerial equipment is usually not supported by EU authorities (and not well received by the public society) due to environmental concerns such as water contamination and is therefore prohibited in certain EU countries.

Pheromonal Control

As D. virgifera virgifera is a very actively moving beetle with the ability to mate throughout its entire lifespan, pheromonal control is limited. However, semiochemicals have been used to develop insecticide baits (Metcalf et al., 1987).

The pheromone for D. virgifera virgifera is (2R,8R) 8-methyl-2-decyl propanoate. The four stereoisomers of 8-methyl-2-decyl propanoate were tested for attractiveness to D. virgifera virgifera. The (2R,8R)- configuration was most attractive while (2R,8R), (2S,8R)- or (2S,8S)-isomers were neither attractive nor repellent (Guss et al., 1985).

The synthetic maize volatiles geranylacetone and alpha-terpineol attract D. virgifera virgifera and D. barberi (Hammack, 1996).

Active volatiles from Cucurbita blossoms contain 1,2,4-trimethoxygenzene, indole and (E)-cinnamaldehyde. This mixture represents an optimised Cucurbita blossom attractant volatile kairomone mixture useful in monitoring Diabrotica populations and in studying their behaviour and ecology (Metcalf et al., 1995). Other volatiles attractive to D. virgifera virgifera include 4-methoxycinnamaldehyde, 4-methosycinnamonitrile, beta-ionone and estragole. In field trapping tests, phenyl alkyl amines and phenyl alkyl alcohols with 2-carbon side chains attracted significantly more adults than did phenyl alkyl amines or phenyl alkyl alcohols with 1-, 3- or 4-carbon side chains. Cinnamaldehyde attracted the most D. virgifera virgifera of both sexes. Male D. virgifera virgifera only responded to cinnamaldehyde (Petroski and Hammack, 1998).

Early Warning Systems

Pheromone baited traps are commercially available in North America and Europe and are usually used to detect early infestations with adults of D. virgifera virgifera. Monitoring adults in one season provides a reasonably accurate forecast for damage in the following season (Levine and Gray, 1994).

Field Monitoring/Economic Threshold Levels

Monitoring

The monitoring of high population levels of larvae is easily accomplished, whereas the monitoring of low population levels and the quantitative measurements of larval densities are more labour intensive. To detect high population levels of larvae and to determine the need for control in areas where maize is grown continuously without crop rotation, heavy larval damage can be measured. 'Goose-necking' of the maize stalk prior to flowering indicates root damage, which is often caused by rootworm larval feeding (Krysan and Miller, 1986). The larvae can be detected in June upon excavation of the plants, or the damage to the maize roots can be rated in early July. To detect larvae, 10 to 20 randomly selected maize roots with surrounding soil have to be excavated per field <5 ha) with cores or with a shovel (Bergmann et al., 1981). To achieve a rough estimate of population levels, 30 systematically chosen plant roots have to be excavated per hectare. Larvae can be counted by hand-search over black plastic sheets or in Berlese-Tullgren-funnels. In the same sampling programme, maize roots can be collected, washed, and larval damage can be rated according to root-rating scales, i.e. the Iowa traditional scale 1 to 6 (Hills and Peters, 1971) or the node-injury scale 0.00 to 3.00 (Oleson et al., 2005).

To monitor low population levels of D. virgifera virgifera adults in July and August, baited sticky traps are most effective (Gerber et al., 2005). The sex pheromone racemic 8-methyl-2-decane2-ol-propanoate serves as bait on a transparent sticky trap to capture males with high sensitivity (Toth et al., 2003). One trap per field <5 ha) can be placed at the ear level of the maize plant and the increase in adult populations can be monitored until their number exceeds 100 per trap per week (Toepfer and Kuhlmann, 2004b).

To estimate high population levels of adults and to follow their temporal occurrence, three methods are commonly implemented from late June until September or at least during the period just before silking until the end of silking (Gerber et al., 2005). For determination of economic thresholds these methods should be implemented after mid-July. Monitoring adults in one season gives a reasonably good forecast for damage in the following season (Levine and Gray, 1994; Shaw et al., 1984).

Adults can be counted visually on five whole plants in each of 10 randomly selected sites in a maize field (Baca et al., 1995; Hesler and Sutter, 1993). Samples should be taken in a 'U'-shape to ensure that samples are taken from each quarter of the field.

The adults can be counted visually by examining the ear zone of five plants at 32 random sites per field (for a total of 160 plants), accounting for approximately 50% of the adult number per plant. A sequential sampling table is available and can save time when dealing with high populations (Hein and Foster, 1988).

Less labour intensive monitoring methods involve two trap types: (a) The non-baited yellow sticky trap is a simple, inexpensive and commonly used trap to capture males and females with low sensitivity. Two traps per field of <5 ha and up to four traps in larger fields have to be placed at ear level of the maize plants (Hesler and Sutter, 1993) and changed every 3 to 4 weeks. To achieve a rough estimation of population levels, 12 traps have to be placed per field, each approximately 20 m apart. (b) The floral kairomone, 4-methoxy cinnamaldehyde (MCA) plus indole, serves as a bait on a yellow sticky trap to capture females and males at higher sensitivity than the non-baited yellow sticky trap, and males at four times lower sensitivity than the pheromone sticky trap (Zoltan et al., 2001). One trap per field <5 ha) has to be placed at the ear level of the maize plant and changed every 3 to 4 weeks.

Population growth

Several models were developed to predict population growth of Diabrotica spp. (Elliott et al., 1990; Tollefson, 1990; Elliott and Hein, 1991; Schaafsma et al., 1993; Szalai et al., 2011). A rough estimate is that a D. virgifera virgifera population in an isolated, weed-free monoculture field builds up to its maximum population within 4 to 5 years with an annual growth rate of 4. In areas with large-scale maize production and neighbouring infested fields, major population increase is observed in the first and second year after infestation of a field.

Economic thresholds

Economic thresholds are expressed by (1) the number of larvae per plant in root-soil samples, (2) rating the root damage, or (3) the average and cumulative numbers of adults per plant (Gerber et al., 2005):

(1) About 8 to 10 third-instar larvae per plant root are often estimated to cause economic damage in commercial maize at 60,000 plants per hectare, depending on local requirements (Toepfer and Kuhlmann, 2004b).

(2) In the root damage rating system, the value 2.5 or 3 on the traditional IOWA scale is considered as economic damage (Turpin and Maxwell, 1976). A new linear decimal 0.00-3.00 node injury scale has lately been used to rate root damage (Oleson et al., 2005). On this scale the suggested economic threshold level in conventional grain maize is at 0.25 for the corn belt of the USA and 0.75 for irrigated conventional maize growing in northern Italy (Edwards et al., 2010).

(3) More than 0.75 to 1 adult per whole plant on average have to be recorded several times from mid-July until the beginning of August to meet the economic threshold necessary to control D. virgifera virgifera in the following year (Turpin et al., 1972; Stamm et al., 1985). The threshold for damage in the current year of commercial maize produc­tion is about 5 to 10 adults per whole plant. At 0.5 adults per whole plant, rotation of the crop is recom­mended for the following year. When more than 6 adults are captured per yellow sticky trap on average per day, economic damage is expected in the following year (Baca et al., 1995). Unfortunately, counting larvae or adults does not provide reliable estimations of absolute population densities, as larvae and adult distributions are clumped (Ellsbury et al., 1996). Furthermore, all recommendations depend on regional weather and soil conditions as well as on the maize variety, e.g. sweet, commercial or seed maize (Baca et al., 1995), and finally on the infestation of neighbouring fields.

IPM Programmes

The application of one control option alone will not control this pest in the long term (Onstad et al., 2001; Toepfer et al., 2005b). The main elements of D. virgifera virgifera management include monitoring pest populations (principally adults), use of economic thresholds, and integration of control tactics (including crop rotation, insecticide treatment, transgenic Bt maize and in the future, applications of entomopathogenic nematodes and/or fungi) (Nishimatsu and Jackson, 1998; Toepfer and Kuhlmann, 2004b).

General IPM guidelines for maize growing in Europe are published by IOBC (Boller et al., 1997).

References

Top of page

Aldrich SR; Scott WO; Hoeft RG, 1986. Modern Corn Production. Champaign, Illinois, USA: A & L Publications Inc.

Assabgui RA; Arnason JT; Hamilton RI, 1993. Hydroxamic acid content in maize (Zea mays) roots of 18 Ontario recommended hybrids and prediction of antibiosis to the western corn rootworm, Diabrotica virgifera LeConte (Coleoptera: Chrysomelidae). Canadian Journal of Plant Science, 73(1):359-363.

Baca F, 1994. New member of the harmful entomofauna of Yugoslavia Diabrotica virgifera virgifera LeConte (Coleoptera, Chrysomelidae). Zastita Bilja, 45(2):125-131

Baca F; Camprag D; Keresi T; Krnjajic S; Manojlovic B; Sekulic R; Sivcev I, 1995. Western corn rootworm Diabrotica virgifera virgifera LeConte. In: Camprag D, ed. Kukuruzna Zlatica, Drustvo za zasitu bilja Serbije. Studio Stanisic, Beograd, pp 112.

Baufeld P; Enzian S, 2005. Maize growing, maize high-risk areas and potential yield losses due to western corn rootworm (Diabrotica virgifera virgifera) damage in selected European countries. In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management. Wallingford, UK: CAB International, 285-302.

Baum JA; Bogaert T; Clinton W; Heck GR; Feldmann P; Ilagan O; Johnson S; Plaetinck G; Munyikwa T; Pleau M; Vaughn T; Roberts J, 2007. Control of coleopteran insect pests through RNA interference. Nature Biotechnology, 25(11):1322-1326. http://www.nature.com/nbt/

Bergman MK; Tollefson JJ; Hinz PN, 1981. Sampling scheme for estimating populations of corn rootworm larvae. Environmental Entomology, 10(6):986-990

Boetel MA; Fuller BW, 1997. Seasonal emergence-time effects on adult longevity, fecundity, and egg viability of northern and western corn rootworms (Coleoptera: Chrysomelidae). Environmental Entomology, 26(6):1208-1212; 11 ref.

Boetel MA; Fuller BW; Chandler LD; Hovland DG; Evenson PD, 1998. Fecundity and egg viability of northern and western corn rootworm (Coleoptera: Chrysomelidae) beetles surviving labelled and reduced soil insecticide applications. Journal of Economic Entomology, 91(1):274-279; 18 ref.

Boetel MA; Fuller BW; Evenson PD, 2003. Emergence of adult northern and western corn rootworms (Coleoptera: Chrysomelidae) following reduced soil insecticide applications. Journal of Economic Entomology, 96(3):714-729.

Boller EF; Malavolta C; Joerg E, 1997. Guidelines for integrated production of arable crops in Europe: technical guideline 3. IOBC/WPRS Bulletin, 20:2-10.

Borg T, 2014. 2014/63/EU: Commission recommendation of 6 February 2014 on measures to control Diabrotica virgifera virgifera Le Conte in Union areas where its presence is confirmed. 2014/63/EU: Commission recommendation of 6 February 2014 on measures to control Diabrotica virgifera virgifera Le Conte in Union areas where its presence is confirmed. Brussels, Belgium: European Union. http://eur-lex.europa.eu/legal-content/EN/TXT/?uri=CELEX:32014H0063

Boriani M; Agosti M; Kiss J; Edwards CR, 2006. Sustainable management of the western corn rootworm, Diabrotica virgifera virgifera LeConte (Coleoptera: Chrysomelidae), in infested areas: experiences in Italy, Hungary and the USA. Bulletin OEPP/EPPO Bulletin, 36(3):531-537. http://www.blackwell-synergy.com/servlet/useragent?func=showIssues&code=epp

Branson TF; Ortman EE, 1967. Host range of larvae of the western corn rootworm. Journal of Economical Entomology, 60:201-203.

Branson TF; Ortman EE, 1970. The host range of larvae of the western corn rootworm: further studies. Journal of Economical Entomology, 63:800-803.

Branson TF; Ortman EE, 1971. Host range of larvae of the northern corn rootworm: further studies. Journal of the Kansas Entomological Society, 44(1):50-52

Branson TF; Sutter GR; Fisher JR, 1982. Comparison of a tolerant and a susceptible maize inbred under artificial infestations of Diabrotica virgifera virgifera: yield and adult emergence. Environmental Entomology, 11(2):371-372

Breitenbach S; Heimbach U; Lauer KF, 2005. Field tests on the host range of the larvae of the Western Corn Rootworm (Diabrotica v. virgifera). Nachrichtenblaetter des Deutschen Pflanzenschutzdienstes 57:241-244.

Brooks WM; Jackson JJ, 1990. Eugregarines: current status as pathogens, illustrated in corn rootworms. Proceedings and abstracts, Vth International Colloquium on Invertebrate Pathology and Microbial Control, Adelaide, Australia, 20-24 August 1990 Glen Osmond, Australia; Department of Entomology, University of Adelaide, 512-515

Burand JP; Hunter WB, 2013. RNAi: future in insect management. Journal of Invertebrate Pathology [Tse Tse Fly Symposium, March 2013.], 112(Suppl. 1):S68-S74. http://www.sciencedirect.com/science/article/pii/S0022201112001814

Byrne D, 2003. Commission decision 2003/766/EC of 24 October 2003 on emergency measures to prevent the spread within the community of Diabrotica virgifera LeConte. EC document C, 3880.

Cabanillas HE; Wright RJ; Vyas RV, 2005. Cereal, fibre, oilseed and medicinal crop applications. In: Grewal PS, Ehlers RU, Shapiro DI, eds. Nematodes as Biocontrol Agents. Wallingford, UK: CABI Publishing, 265-280.

CABI/EPPO, 1998. Distribution maps of quarantine pests for Europe (edited by Smith IM, Charles LMF). Wallingford, UK: CAB International, xviii + 768 pp.

CABI/EPPO, 2012. Diabrotica virgifera virgifera. [Distribution map]. Distribution Maps of Plant Pests, No.June. Wallingford, UK: CABI, Map 576 (1st revision).

Chandler LD, 1998. Comparison of insecticide-bait aerial application methods for management of corn rootworm (Coleoptera: Chrysomelidae). Southwestern Entomologist, 23(2):147-159; 19 ref.

Chiang HC, 1973. Bionomics of the northern and western corn rootworms. Annual Review of Entomology, 18:47-72

Coats SA; Tollefson JJ; Mutchmor JA, 1986. Study of migratory flight in the western corn rootworm (Coleoptera: Chrysomelidae). Environmental Entomology, 15(3): 620-625.

Devos Y; Meihls LN; Kiss J; Hibbard BE, 2013. Resistance evolution to the first generation of genetically modified Diabrotica-active Bt-maize events by western corn rootworm: management and monitoring considerations. Transgenic Research, 22(2):269-299. http://rd.springer.com/journal/11248

Dicke D; Martinez O; Frosch M; Lenz M; Jung J; Willig W; Jostock M; Kerber M, 2014. First occurrence of western corn root worm beetles in the federal states Hesse and Rhineland-Palatinate (Germany), 2011. Julius-Kühn-Archiv [Proceedings International Conference on the German Diabrotica Research Program, 14-16 November, 2012, Berlin, Germany.], No.444:17. http://pub.jki.bund.de/index.php/JKA/issue/archive

Dunbar MW; Gassmann AJ, 2013. Abundance and distribution of western and northern corn rootworm (Diabrotica spp.) and prevalence of rotation resistance in eastern Iowa. Journal of Economic Entomology, 106(1):168-180. http://esa.publisher.ingentaconnect.com/content/esa/jee/2013/00000106/00000001/art00023

Eben A; Barbercheck ME, 1996. Field observations on host plant associations enemies of diabroticite beetles (Chrysomelidae: Luperini) in Veracruz, Mexico. Acta Zoologica Mexicana, No. 67:47-65; 60 ref.

Edwards CR, 2006. Western corn rootworm. Purdue University, Website developed by the Entomology Department at Purdue University: http://www.entm.purdue.edu/wcr/.

Edwards CR; Agosti M; Michelon L, 2010. The 2010 Diabrotica situation in brescia province of northwestern Italy. IWGO Newsletter, 30(1). 5-7.

Edwards CR; Barcic JI; Berberovic H; Berger HK; Festic H; Kiss J; Princzinger G; Schulten GGM; Vonica I, 1999. Results of the 1997-1998 multi-country FAO activity on containment and control of the western corn rootworm, Diabrotica virgifera virgifera LeConte, in Central Europe. Acta Phytopathologica et Entomologica Hungarica, 34(4):373-386; 5 ref.

El-Khishen AA; Bohn MO; Prischmann-Voldseth DA; Dashiell KE; French BW; Hibbard BE, 2009. Native resistance to western corn rootworm (Coleoptera: Chrysomelidae) larval feeding: characterization and mechanisms. Journal of Economic Entomology, 102(6):2350-2359. http://docserver.ingentaconnect.com/deliver/connect/esa/00220493/v102n6/s42.pdf?expires=1264652303&id=0000&titleid=10264&checksum=A6796122213E7EAE26F538D4A1A4BD89

Elliott NC; Gustin RD; Hanson SL, 1990. Influence of adult diet on the reproductive biology and survival of the western corn rootworm, Diabrotica virgifera virgifera. Entomologia Experimentalis et Applicata, 56(1):15-21.

Elliott NC; Hein GL, 1991. Population dynamics of the western corn rootworm: formulation, validation, and analysis of a simulation model. Ecological Modelling, 59(1-2):93-122

Elliott NC; Jackson JJ; Gustin RD, 1990. Predicting western corn rootworm beetle (Coleoptera: Chrysomelidae) emergence from the soil using soil or air temperature. Canadian Entomologist, 122(11-12):1079-1091

Elliott NC; Lance DR; Hanson SL, 1990. Quantitative description of the influence of fluctuating temperatures on the reproductive biology and survival of the western corn rootworm, Diabrotica virgifera virgifera LeConte (Coleoptera: Chrysomelidae). Canadian Entomologist, 122(1-2):59-68.

EPPO, 2011. EPPO Reporting Service. EPPO Reporting Service. Paris, France: EPPO. http://archives.eppo.org/EPPOReporting/Reporting_Archives.htm

EPPO, 2012. EPPO Reporting Service. EPPO Reporting Service. Paris, France: EPPO. http://archives.eppo.org/EPPOReporting/Reporting_Archives.htm

EPPO, 2014. PQR database. Paris, France: European and Mediterranean Plant Protection Organization. http://www.eppo.int/DATABASES/pqr/pqr.htm

Felsot AS; Mitchell JK; Kenimer AL, 1990. Assessment of management practices for reducing pesticide runoff from sloping cropland in Illinois. Journal of Environmental Quality, 19(3):539-545

Fisher DC, 1983. Celatoria diabroticae Shimer and Celatoria setosa Coquillett: Tachinid parasitoids of the Diabroticite Coleoptera. University of Illinois at Urbana-Champaign, Illinois.

Fisher JR, 1989. Hatch of Diabrotica virgifera virgifera (Coleoptera: Chrysomelidae) eggs exposed to two different overwintering and hatch regimes. Journal of the Kansas Entomological Society, 62(4):607-610

Furlan L; Canzi S; Bernardo Adi; Edwards CR, 2006. The ineffectiveness of insecticide seed coatings and planting-time soil insecticides as Diabrotica virgifera virgifera LeConte population suppressors. Journal of Applied Entomology, 130(9/10):485-490. http://www.blackwell-synergy.com/servlet/useragent?func=showIssues&code=jen

Furlan L; Vettorazzo M; Frausin C, 2002. Diabrotica virgifera virgifera LeConte: what has been done and what will be done in Italy?. Acta Phytopathologica et Entomologica Hungarica, 37(1/3):169-173; 10 ref.

Gassmann AJ; Petzold-Maxwell JL; Keweshan RS; Dunbar MW, 2011. Field-evolved resistance to Bt maize by western corn rootworm. PLoS ONE, No.July:e22629. http://www.plosone.org/article/info%3Adoi%2F10.1371%2Fjournal.pone.0022629

Gassmann AJ; Petzold-Maxwell JL; Keweshan RS; Dunbar MW, 2012. Western corn rootworm and Bt maize: challenges of pest resistance in the field. GM Crops, 3(3):235-244. http://www.landesbioscience.com/journals/gmcrops/article/20744/?show_full_text=true#

Gassmann AJ; Weber P, 2013. 2013 Iowa evaluation of insecticides and plant-incorporated protectants. 2013 Iowa evaluation of insecticides and plant-incorporated protectants. Ames, Iowa: Department of Entomology, Iowa State University, 51 pp. http://www.ent.iastate.edu/dept/faculty/gassmann/files/page/files/2013_Ent_Report.pdf

Gerber CK; Edwards CR; Bledsoe LW; Obermeyer JL; Barna G; Foster RE, 2005. Sampling devices and decision rule development for western corn rootworm (Diabrotica virgifera virgifera LeConte) adults in soybean to predict subsequent damage to maize in Indiana. In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management, 169-187.

Gerginov L; Tomov N, 1995. The western corn rootworm - Diabrotica virgifera virgifera LeConte (Coleoptera: Chrysomelidae) - a new quarantine pest of maize. Rasteniev"dni Nauki, 32(9/10):159-160; 8 ref.

Grant RH; Seevers KP, 1989. Local and long-range movement of adult western corn rootworm (Coleoptera: Chrysomelidae) as evidenced by washup along southern Lake Michigan shores Environmental Entomology, 18(2):266-272.

Gray ME; Felsot AS; Steffey KL; Levine E, 1992. Planting time application of soil insecticides and western corn rootworm (Coleoptera, Chrysomelidae) emergence - implications for long term management programs. Journal of Economic Entomology, 85(2):544-553.

Gray ME; Levine E; Oloumi-Sadeghi H, 1998. Adaptation to crop rotation: western and northern corn rootworms respond uniquely to a cultural practice. Recent Research Developments in Entomology, 2:19-31; 59 ref.

Gray ME; Sappington TW; Miller NJ; Moeser J; Bohn MO, 2009. Adaptation and invasiveness of western corn rootworm: intensifying research on a worsening pest. Annual Review of Entomology, 54:303-321. http://www.annualreviews.org

Guss PL; Sonnet PE; Carney RL; Tumlinson JH; Wilkin PJ, 1985. Response of northern corn rootworm, Diabrotica barberi Smith and Lawrence, to stereoisomers of 8-methyl-2-decyl propanoate. Journal of Chemical Ecology, 11(1):21-26.

Hammack L, 1996. Corn volatiles as attractants for northern and western corn rootworm beetles (Coleoptera: Chrysomelidae: Diabrotica spp.). Journal of Chemical Ecology, 22(7):1237-1253; 46 ref.

Hein GL; Foster RE, 1988. Corn rootworm management. IOWA State University.

Hesler LS; Sutter GR, 1993. Effect of trap color, volatile attractants, and type of toxic bait dispenser on captures of adult corn rootworm beetles (Coleoptera: Chrysomelidae). Environmental Entomology, 22(4):743-750

Hills TM; Peters DC, 1971. A method of evaluating postplanting insecticide treatments for control of western corn rootworm larvae. Journal of Economical Entomology, 64:764-765.

Inglis GD; Goettel MS; Butt TM; Strasser H, 2001. Use of hyphomycetous fungi for managing insect pests. Fungi as biocontrol agents: progress, problems and potential, 23-69; many ref.

IPPC, 2006. IPP Report No. NL-2/1. Rome, Italy: FAO.

IPPC, 2010. Situation of Diabrotica virgifera virgifera in Belgium. IPPC Official Pest Report, No. BEL-03/1. Rome, Italy: FAO. https://www.ippc.int/

IPPC, 2013. New finding of Diabrotica virgifera virgifera. IPPC Official Pest Report, No. GBR-33/1. Rome, Italy: FAO.

IPPC, 2014. New finding of Diabrotica virgifera virgifera. IPPC Official Pest Report, No. GBR-33/2, No. GBR-33/2. Rome, Italy: FAO. https://www.ippc.int/

Isard SA; Spencer JL; Nasser MA; Levine E, 2000. Aerial movement of western corn rootworm (Coleoptera: Chrysomelidae): diel periodicity of flight activity in soybean fields. Environmental Entomology, 29(2):226-234; 49 ref.

Ivezic M; Raspudic E; Brmez M; Majic I; Brkic I; Tollefson JJ; Bohn M; Hibbard BE; Simic D, 2009. A review of resistance breeding options targeting western corn rootworm (Diabrotica virgifera virgifera LeConte). Agricultural and Forest Entomology, 11(3):307-311. http://www.blackwell-synergy.com/loi/afe

Jackson JJ; Elliott NC, 1988. Temperature-dependent development of immature stages of the western corn rootworm, Diabrotica virgifera virgifera (Coleoptera: Chrysomelidae). Environmental Entomology, 17(2):166-171.

Jensen SG, 1985. Laboratory transmission of maize chlorotic mottle virus by three species of corn rootworms. Plant Disease, 69(10):864-868

Kim KS; Sappington TW, 2005. Genetic structuring of western corn rootworm (Coleoptera: Chrysomelidae) populations in the United States based on microsatellite loci analysis. Environmental Entomology, 34:494-503.

Kinney KK; Maddox JV; Dazey DM; McKinnis MW, 1989. Field evaluations of Beauveria bassiana for control of corn rootworm larvae: root protection and yield. Urbana Champaign Illinois insecticide evaluation: forage, field and vegetable crops. University of Illinois, Illinois, 28-32.

Kiss J; Edwards CR; Berger HK; Cate P; Cean M; Cheek S; Derron J; Festic H; Furlan L; Igrc-Barcic J; Ivanova I; Lammers W; Omelyuta V; Princzinger G; Reynaud P; Sivcev I; Sivicek P; Urek G; Vahala O, 2005. Monitoring of western corn rootworm (Diabrotica virgifera virgifera LeConte) in Europe 1992-2003. In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management, 29-39.

Kiss J; Komáromi J; Bayar K; Edwards CR; Hatala-Zsellér I, 2005. Western corn rootworm (Diabrotica virgifera virgifera LeConte) and the crop rotation systems in Europe. In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management, 189-220.

Knutson RJ; Hibbard BE; Barry BD; Smith VA; Darrah LL, 1999. Comparison of screening techniques for western corn rootworm (Coleoptera: Chrysomelidae) host-plant resistance. Journal of Economic Entomology, 92(3):714-722; 26 ref.

Krysan JL; Jackson JJ; Lew AC, 1984. Field termination of egg diapause in Diabrotica with new evidence of extended diapause in D. barberi (Coleoptera: Chrysomelidae). Environmental Entomology, 13(5):1237-1240.

Krysan JL; McDonald IC; Tumlinson JH, 1989. Phenogram based on allozymes and its relationship to classical biosystematics and pheromone structure among eleven Diabroticites (Coleoptera: Chrysomelidae). Annals of the Entomological Society of America, 82(5):574-581.

Krysan JL; Miller TA(Editors), 1986. Methods for the study of pest Diabrotica. New York, USA: Springer-Verlag, 260pp.

Krysan JL; Smith RF, 1987. Systematics of the virgifera species group of Diabrotica (Coleoptera: Chrysomelidae: Galerucinp). Entomography, 5:375-484.

Krysan JL; Smith RF; Branson TF; Guss PL, 1980. A new subspecies of Diabrotica virgifera (Coleoptera: Chrysomelidae): description, distribution, and sexual compatibility. Annals of the Entomological Society of America, 73(2):123-130.

Kuhlmann U; Burgt WACMvan der, 1998. Possibilities for biological control of the western corn rootworm, Diabrotica virgifera virgifera LeConte, in Central Europe. Biocontrol News and Information, 19(2):59-68; 4 ref.

Kuhlmann U; Toepfer S; Zhang F, 2005. Is classical biological control against western corn rootworm in Europe a potential sustainable management strategy? In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management, 263-284.

Kuhlmann U; van der Burgt WACM, 1998. Possibilities for biological control of the western corn rootworm, Diabrotica virgifera virgifera Le Conte, in Central Europe. Biocontrol News and Information, 19(2): 59N-68N.

Levine E; Chan SY, 1990. A bibliography of the northern and western corn rootworm: an update 1977 through 1988. Illinois Natural History Survey Biological Notes, No. 135:29 pp.

Levine E; Gray ME, 1994. Use of cucurbitacin vial traps to predict corn rootworm (Coleoptera: Chrysomelidae) larval injury in a subsequent crop of corn. Journal of Entomological Science, 29(4):590-600

Levine E; Oloumi-Sadeghi H, 1991. Management of diabroticite rootworms in corn. Annual Review of Entomology, 36:229-255.

Levine E; Oloumi-Sadeghi H; Ellis CR, 1992. Thermal requirements, hatching patterns, and prolonged diapause in western corn rootworm (Coleoptera: Chrysomelidae) eggs. Journal of Economic Entomology, 85(6):2425-2432

Levine E; Spencer JL; Isard SA; Onstad DW; Gray ME, 2002. Adaptation of the western corn rootworm to crop rotation: evolution of a new strain in response to a management practice. American Entomologist, 48(2):94-117. http://www.entsoc.org/pubs/periodicals/ae/AE-2002/summer/Summer-contents.pdf

Meinke LJ; Sappington TW; Onstad DW; Guillemaud T; Miller NJ; Komáromi J; Levay N; Furlan L; Kiss J; Toth F, 2009. Western corn rootworm (Diabrotica virgifera virgifera LeConte) population dynamics. Agricultural and Forest Entomology, 11(1):29-46. http://www.blackwell-synergy.com/loi/afe

Meinke LJ; Siegfried BD; Wright RJ; Chandler LD, 1998. Adult susceptibility of Nebraska western corn rootworm (Coleoptera: Chrysomelidae) populations to selected insecticides. Journal of Economic Entomology, 91(3):594-600; 17 ref.

Meissle M; Romeis J; Bigler F, 2011. Bt maize and integrated pest management - a European perspective. Pest Management Science, 67(9):1049-1058. http://onlinelibrary.wiley.com/doi/10.1002/ps.2221/abstract

Metcalf RL, 1986. Forward In: Methods for the Study of Pest Diabrotica. Krysan JL, Miller TA, eds. New York, USA: Springer-Verlag, 260pp.

Metcalf RL; Ferguson JE; Lampman R; Andersen JF, 1987. Dry cucurbitacin-containing baits for controlling diabroticite beetles (Coleoptera: Chrysomelidae). Journal of Economic Entomology, 80(4):870-875.

Metcalf RL; Lampman RL; Deem-Dickson L, 1995. Indole as an olfactory synergist for volatile kairomones for diabroticite beetles. Journal of Chemical Ecology, 21(8):1149-1162.

Michaelakis AN; Papadopoulos NT; Antonatos SA; Zarpas K; Papachristos DP, 2010. First data on the occurrence of Diabrotica virgifera virgifera Le Conte (Coleoptera: Chrysomelidae) in Greece. Hellenic Plant Protection Journal, 3(1):29-32. http://www.bpi.gr

Miller N; Estoup A; Toepfer S; Bourguet D; Lapchin L; Derridj S; Kim KS; Reynaud P; Furlan L; Guillemaud T, 2005. Multiple transatlantic introductions of the western corn rootworm. Science (Washington), 310:992.

Miyata K; Ramaseshadri P; Zhang YJ; Segers G; Bolognesi R; Tomoyasu Y, 2014. Establishing an in vivo assay system to identify components involved in environmental RNA interference in the western corn rootworm. PLoS ONE, 9(7):e101661. http://www.plosone.org/article/info%3Adoi%2F10.1371%2Fjournal.pone.0101661

Moeser J, 2003. Nutritional ecology of the invasive maize pest Diabrotica v. virgifera LeConte in Europe. Faculty of Agricultural Sciences. Georg-August-University, Goettingen, Germany, pp. 89.

Moeser J; Hibbard BE, 2005. A synopsis of the nutritional ecology of larvae and adults of Diabrotica virgifera virgifera (LeConte) in the new and old world - nouvelle cuisine for the invasive maize pest Diabrotica virgifera virgifera in Europe? In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management, pp. 41-65.

Musick GJ; Chiang HC; Luckmann WH; Mayo ZB; Turpin FT, 1980. Impact of planting dates of field corn on beetle emergence and damage by the western and the northern corn rootworms in the corn belt. Annals of the Entomological Society of America, 73(2):207-215.

Naranjo SE; Sawyer AJ, 1987. Reproductive biology and survival of Diabrotica barberi (Coleoptera: Chrysomelidae): effect of temperature, food, and seasonal time of emergence. Annals of the Entomological Society of America, 80(6):841-848.

Narva KE; Siegfried BD; Storer NP, 2013. Transgenic approaches to Western corn rootworm control. In: Yellow biotechnology II: Insect biotechnology in plant protection and industry. Advances in biochemical engineering-biotechnology, 136 [ed. by Vilcinskas, A.]. Berlin, Germany: Springer-Verlag Berlin.

Nishimatsu T; Jackson JJ, 1998. Interaction of insecticides, entomopathogenic nematodes, and larvae of the western corn rootworm (Coleoptera: Chrysomelidae). Journal of Economic Entomology, 91(2):410-418; 24 ref.

Oleson JD; Park YL; Nowatzki TM; Tollefson JJ, 2005. Node-injury scale to evaluate root injury by corn rootworms (Coleoptera: Chrysomelidae). Journal of Economic Entomology, 98:1-8.

Onstad DW; Guse CA; Spencer JL; Levine E; Gray ME, 2001. Modeling the dynamics of adaptation to transgenic corn by western corn rootworm (Coleoptera: Chrysomelidae). Journal of Economic Entomology, 94(2):529-540.

Onstad DW; Joselyn MG; Isard SA; Levine E; Spencer JL; Bledsoe LW; Edwards CR; Fonzo CDdi; Willson H, 1999. Modeling the spread of western corn rootworm (Coleoptera: Chrysomelidae) populations adapting to soybean-corn rotation. Environmental Entomology, 28(2):188-194; 17 ref.

Onstad DW; Meinke LJ, 2010. Modeling evolution of Diabrotica virgifera virgifera (Coleoptera: Chrysomelidae) to transgenic corn with two insecticidal traits. Journal of Economic Entomology, 103(3):849-860. http://docserver.ingentaconnect.com/deliver/connect/esa/00220493/v103n3/s35.pdf?expires=1278410682&id=0000&titleid=10264&checksum=5E5593A73B595C87A10831AF47ED3B19

Ostlie K; Noetzel D, 1987. Managing corn rootworms. University of Minnesota.

Petroski RJ; Hammack L, 1998. Structure activity relationships of phenyl alkyl alcohols, phenyl alkyl amines, and cinnamyl alcohol derivatives as attractants for adult corn rootworm (Coleoptera: Chrysomelidae: Diabrotica spp.). Environmental Entomology, 27(3):688-694; 33 ref.

Pilz C; Keller S; Kuhlmann U; Toepfer S, 2009. Comparative efficacy assessment of fungi, nematodes and insecticides to control western corn rootworm larvae in maize. BioControl, 54(5):671-684. http://www.springerlink.com/link.asp?id=102853

Pilz C; Wegensteiner R; Keller S, 2007. Selection of entomopathogenic fungi for the control of the western corn rootworm Diabrotica virgifera virgifera. Journal of Applied Entomology, 131(6):426-431. http://www.blackwell-synergy.com/loi/jen

Pistorius J; Bischoff G; Heimbach U; Stähler M, 2009. Bee poisoning incidents in Germany in spring 2008 caused by abrasion of active substance from treated seeds during sowing of maize. Julius-Kühn-Archiv [Hazards of pesticides to bees. 10th International Symposium of the ICP-Bee Protection Group. Bucharest, Romania, 8-10 October, 2008.], No.423:118-126. http://pub.jki.bund.de/index.php/JKA/issue/archive

Rozen Kvan; Ester A, 2010. Chemical control of Diabrotica virgifera virgifera LeConte. Journal of Applied Entomology [International Working Group on Ostrinia and other Maize Pests (IWGO). 23rd IWGO Conference, Munich, Germany, 5-8 April 2009.], 134(5):376-384. http://www.blackwell-synergy.com/loi/jen

Rudeen ML; Jaronski ST; Petzold-Maxwell JL; Gassmann AJ, 2013. Entomopathogenic fungi in cornfields and their potential to manage larval western corn rootworm Diabrotica virgifera virgifera. Journal of Invertebrate Pathology, 114(3):329-332. http://www.sciencedirect.com/science/article/pii/S002220111300147X

Schaafsma AW; Fuentes JD; Gillespie TJ; Whitfield GH; Ellis CR, 1993. Performance of a model for egg hatching of the western corn rootworm, Diabrotica virgifera virgifera LeConte, using measured and modelled soil temperatures as input. International Journal of Biometeorology, 37(1):11-18

Schaafsma AW; Whitfield GH; Ellis CR, 1991. A temperature-dependent model of egg development of the western corn rootworm, Diabrotica virgifera virgifera LeConte (Coleoptera: Chrysomelidae). Canadian Entomologist, 123(6):1183-1197.

Scharf ME; Siegfried BD; Meinke LJ; Wright RJ; Chandler LD, 2000. Cytochrome P450-mediated N-demethylation activity and induction in insecticide-resistant and susceptible western corn rootworm populations (Coleoptera: Chrysomelidae). Pesticide Biochemistry and Physiology, 67(2):137-143; 23 ref.

Shaw JT; Ruesink WG; Briggs SP; Luckmann WH, 1984. Monitoring populations of corn rootworm beetles (Coleoptera: Chrysomelidae) with a trap baited with cucurbitacins. Journal of Economic Entomology, 77(6):1495-1499.

Siegfried BD; Mullin CA, 1990. Effects of alternative host plants on longevity, oviposition, and emergence of western and northern corn rootworms (Coleoptera: Chrysomelidae). Environmental Entomology, 19(3):474-480.

Sivcev I; Manojlovic B; Krnjajic S; Dimic N; Draganic M; Baca F; Kaitovic Z; Sekulic R; Keresi T, 1994. Distribution and harmfulness of Diabrotica virgifera LeConte (Coleoptera, Chrysomelidae), a new maize pest in Yugoslavia. Zastita Bilja, 45(1):19-26

Stamm DE; Mayo ZB; Campbell JB; Witkowski JF; Andersen LW; Kozub R, 1985. Western corn rootworm (Coleoptera: Chrysomelidae) beetle counts as a means of making larval control recommendations in Nebraska. Journal of Economic Entomology, 78(4):794-798

Storer NP; Thompson GD; Head GP, 2012. Application of pyramided traits against Lepidoptera in insect resistance management for Bt crops. GM Crops, 3(3):154-162. http://www.landesbioscience.com/journals/gmcrops/article/20945/?show_full_text=true#

Szalai M; Kiss J; Kövér S; Toepfer S, 2014. Simulating crop rotation strategies with a spatiotemporal lattice model to improve legislation for the management of the maize pest Diabrotica virgifera virgifera. Agricultural Systems, 124:39-50. http://www.sciencedirect.com/science/article/pii/S0308521X13001339

Szalai M; Komáromi JP; Bazok R; Barcic JI; Kiss J; Toepfer S, 2011. Generational growth rate estimates of Diabrotica virgifera virgifera populations (Coleoptera: Chrysomelidae). Journal of Pest Science, 84(1):133-142. http://www.springerlink.com/content/1421704q7w3825rq/

T=th F; Horvßth L; Komßromi J; Kiss J; SzTll E, 2002. Field data on the presence of spiders preying on western corn rootworm (Diabrotica virgifera virgifera LeConte) in Szeged Region, Hungary. Acta Phytopathologica et Entomologica Hungarica, 37(1/3):163-168; 13 ref.

Tallamy DW; Hibbard BE; Clark TL; Gillespie JJ, 2005. Western corn rootworm, cucurbits and cucurbitacins. In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management, 67-93.

Tinsley NA; Estes RE; Gray ME, 2013. Validation of a nested error component model to estimate damage caused by corn rootworm larvae. Journal of Applied Entomology, 137(3):161-169. http://onlinelibrary.wiley.com/journal/10.1111/(ISSN)1439-0418

Toepfer S; Burger R; Ehlers RU; Peters A; Kuhlmann U, 2010. Controlling western corn rootworm larvae with entomopathogenic nematodes: effect of application techniques on plant-scale efficacy. Journal of Applied Entomology [International Working Group on Ostrinia and other Maize Pests (IWGO). 23rd IWGO Conference, Munich, Germany, 5-8 April 2009.], 134(5):467-480. http://www.blackwell-synergy.com/loi/jen

Toepfer S; Gueldenzoph C; Ehlers RU; Kuhlmann U, 2005. Screening of entomopathogenic nematodes for virulence against the invasive western corn rootworm, Diabrotica virgifera virgifera (Coleoptera: Chrysomelidae) in Europe. Bulletin of Entomological Research, 95:473-482.

Toepfer S; Hatala-Zseller I; Ehlers RU; Peters A; Kuhlmann U, 2010. The effect of application techniques on field-scale efficacy: can the use of entomopathogenic nematodes reduce damage by western corn rootworm larvae? Agricultural and Forest Entomology, 12(4):389-402. http://onlinelibrary.wiley.com/doi/10.1111/j.1461-9563.2010.00487.x/full

Toepfer S; Kiss J; Turoczi G; Komaromi J; Kuhlmann U, 2005. Options for developing integrated control measures against the maize pest Diabrotica virgifera virgifera LeConte (Coleoptera: Chrysomelidae) in Europe. IOBC/WPRS Bulletin, Vol. 28(2).

Toepfer S; Kuhlmann U, 2004. IPM strategies for the Western Corn Rootworm (Coleoptera: Chrysomelidae): current status and potential adoptations to the European maize productions system. Mitteillungen Deutsche Gesellschaft Allg. Angewandte Entomologie.

Toepfer S; Kuhlmann U, 2004. Survey for natural enemies of the invasive alien chrysomelid, Diabrotica virgifera virgifera, in Central Europe. BioControl, 49:385-395.

Toepfer S; Kuhlmann U, 2005. Natural mortality factors acting on western corn rootworm populations: a comparison between the United States and Central Europe. In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management. Wallingford, UK: CAB International, 95-119.

Tollefson JJ, 1990. Comparison of adult and egg sampling for predicting subsequent populations of western and northern corn rootworms (Coleoptera: Chrysomelidae). Journal of Economic Entomology, 83(2):574-579

Tóth M; Sivcev I; Ujváry I; Tomasek I; Imrei Z; Horváth P; Szarukán I, 2003. Development of trapping tools for detection and monitoring of Diabrotica v. virgifera in Europe. Acta Phytopathologica et Entomologica Hungarica, 38:307-322.

Turpin FT; Dumenil LC; Peters DC, 1972. Edaphic and agronomic characters that affect potential for rootworm damage to corn in Iowa. Journal of Economic Entomology, 65(6):1615-1619.

Turpin FT; Maxwell JD, 1976. Decision-making related to use of soil insecticides by Indiana corn farmers. Journal of Economic Entomology, 69(3):359-362

Ward DP; DeGooyer TA; Vaughn TT; Head GP; McKee MJ; Astwood JD; Pershing JC, 2005. Genetically enhanced maize as a potential management option for corn rootworm: YieldGard(R) rootworm maize case study. In: Vidal S, Kuhlmann U, Edwards CR, eds. Western Corn Rootworm: Ecology and Management, 239-262.

Wesseler J; Fall EH, 2010. Potential damage costs of Diabrotica virgifera virgifera infestation in Europe - the 'no control' scenario. Journal of Applied Entomology [International Working Group on Ostrinia and other Maize Pests (IWGO). 23rd IWGO Conference, Munich, Germany, 5-8 April 2009.], 134(5):385-394. http://www.blackwell-synergy.com/loi/jen

Xie YS; Arnason JT; Philogene BJR; Lambert JDH; Atkinson J; Morand P, 1990. Role of 2,4-dihydroxy-7-methoxy-1,4-benzoxazin-3-one (DIMBOA) in the resistance of maize to western corn rootworm, Diabrotica virgifera virgifera (Leconte) (Coleoptera: Chrysomelidae). Canadian Entomologist, 122(11-12):1177-1186.

Zhang F; Toepfer S; Riley K; Kuhlmann U, 2004. Reproductive biology of Celatoria compressa (Diptera: Tachinidae), a parasitoid of Diabrotica virgifera virgifera (Coleoptera: Chrysomelidae). Biocontrol Science and Technology, 14:5-16.

Zoltan I; Toth M; Szarukan I; Gazdag T; Szeredi A, 2001. Comparison of performance of different trap types for monitoring of Diabrotica virgifera. IOBC/IWGO Newsletter, 22:7.

Distribution Maps

Top of page
You can pan and zoom the map
Save map
Download KML file Download CSV file
Creative Commons Licence
This work is licensed under a Creative Commons Attribution-NonCommercial-ShareAlike 3.0 Unported License.

Please click OK to ACCEPT or Cancel to REJECT

Creative Commons Licence
This work is licensed under a Creative Commons Attribution-NonCommercial-ShareAlike 3.0 Unported License.

Please click OK to ACCEPT or Cancel to REJECT
